Challenger EW10CK Completion Kit for EW10 Wide Inground Lift

Challenger EW10CK Completion Kit for EW10 Wide Inground Lift Overview

Your cassette is in the ground, the concrete is cured, and you need the above-ground hardware to bring the bay online. The Challenger EW10CK completion kit delivers the superstructure, 3-stage arms, standard pedestal controls, and 2HP power unit for the EW10 series wide inground lift. This is the base configuration: 10,000 lb capacity, 88 inches of extra-wide drive-through clearance, and a straightforward control layout with no added complexity.

The EW10 platform's width is what sets it apart from conventional inground lifts. That 88-inch clearance is wide enough to lower EV battery packs without sacrificing standard cassette functionality for conventional vehicles. Challenger's 3-stage front and rear arms with double-telescoping screw pads give you precise pick-point positioning across a wide vehicle mix, and the bolster-free design means nothing to drive over when pulling vehicles in and out of the bay.

This is the no-frills entry point into the EW10 completion kit lineup. Standard pedestal controls mount adjacent to the lift, the 2HP motor delivers a 41-second rise time, and you're up and running. If you decide later that faster cycle times or bench-mount controls would improve your workflow, those upgrades are available through the QC and BMC kit variants. But for shops that need reliable capacity and EV-width clearance without the extras, the EW10CK gets you there. ALI/ETL certified.

Specifications

• 4x EVFPK Low-Profile EV-Ready Foot Pads
• 4x Universal Foot Pads
• 4x 3-Inch Adapters
• 4x 6-Inch Adapters
• 4x Storage Racks

The completion kit installs onto an existing EW10 cassette and frame that's already set in concrete. The EW10 platform uses a simplified single concrete pour instead of the older three-pour approach, so if your groundwork followed the current spec, you're ready for the above-ground build.

You'll need 208V-230V single-phase power at 60Hz for the 2HP motor, plus shop air between 90 and 120 psi. Standard pedestal controls mount adjacent to the lift, so plan your control placement for easy technician access without obstructing vehicle entry. Professional installation by a qualified lift technician is strongly recommended to maintain warranty coverage and ensure ALI/ETL compliance.

The 88-inch drive-through clearance lets you lower battery packs out of electric vehicles while still functioning as a standard inground lift for conventional service work.

3-stage arms with double-telescoping screw pads reach specific pick-up points on wide-chassis luxury sedans and performance vehicles that narrower lifts can't accommodate.

The base EW10CK configuration gives you 10,000 lb capacity with standard controls and no added complexity. Reliable daily-use lifting for shops that don't need faster cycle times or bench-mount integration.

From compact EVs to full-size trucks, the 10,000 lb capacity and 20" to 42" arm reach cover a wide mix of makes and models without swapping adapters between every job.

This completion kit ships via flatbed freight truck. Our team coordinates the freight shipment and helps manage scheduling details. A tracking number is provided once your order ships, and you'll schedule a delivery appointment directly with the carrier.

You're responsible for unloading at delivery. A forklift or similar equipment is required. If you can't unload on-site, you may be able to pick up from the carrier's nearest freight terminal instead.

Need a delivery window, residential delivery, or liftgate service? Contact us before ordering so we can confirm the best delivery setup and any accessorial charges.

Challenger Lifts provides a limited warranty to the original purchaser covering defects in material and workmanship. Coverage typically includes 1-year labor, with extended structural coverage of up to 5 years on certain inground models. The warranty is non-transferable.

For inground lifts in the 10K-15K range (such as the EW1020 platform), typical coverage includes 1-year labor, 2-year parts, and 5-year structural. Exclusions apply for damage caused by improper installation, lack of maintenance, or unauthorized repairs.

Warranty registration may be required after purchase. Refer to included documentation for details. Claims require the lift's serial number and must be processed through an authorized service representative.

What does the EW10CK completion kit include?

Superstructure, 3-stage arm assemblies, standard pedestal controls, and 2HP power unit. Underground cassette must already be set in concrete.

How does the EW10CK compare to other EW10 kits?

Base config with pedestal controls and 2HP/41-second rise. EW10CK-QC adds 3HP/24-second QC. EW10CK-BMC adds bench-mount controls. EW10CK-BMC-QC combines both. All share 10,000 lb capacity and 88-inch clearance.

Can I upgrade to QuickCycle or BMC later?

QC requires 3HP motor swap. BMC requires workbench integration and rewiring. More cost-effective to start with the right kit variant.

What are the electrical requirements?

208V-230V single-phase 60Hz for 2HP motor. Shop air 90-120 psi required. Single concrete pour for cassette.

Can this lift handle EV battery service?

Yes. 88-inch drive-through clearance allows EV battery pack removal. Optional EV Kit Part #10900 adds EV-specific pads and adapters.

What is the arm reach and screw pad range?

Arm reach 20-42 inches. Screw pad height 4-6.125 inches. 10,000 lb total capacity at 2,500 lbs per arm.

Is the EW10 ALI/ETL certified?

Yes. Both EW1020 and EW1020-QC carry full ALI/ETL certification.

What superstructure colors are available?

Black, Red, or Blue. Confirm color at time of order.

How is the kit shipped?

Flatbed freight truck. Forklift required for unloading. Tracking number and delivery appointment scheduling provided.

What warranty coverage is included?

Limited warranty: 1-year labor, 2-year parts, 5-year structural for 10K-15K inground lifts. Non-transferable. Registration required.
