Challenger EV1020LS-2-QC Inground Lift 10000 lb Quick Cycle

• Set of 2 complete inground lift units in one order
• 10,000 lb capacity per lift with 2,500 lb per arm
• Quick Cycle 27-second rise time, over 40% faster than standard
• ALI/ETL certified sealed polymer cassette design
• 87" drive-thru clearance for wide vehicle access

Challenger EV1020LS-2-QC Inground Lift Features

Set of 2 Quick Cycle Inground Lifts

This listing delivers two complete EV1020 Quick Cycle inground lift units, streamlining procurement for multi-bay installations, facility expansions, or simultaneous lift replacements. Ordering as a set simplifies logistics and ensures both units ship with matched components and serial numbers for coordinated installation scheduling.

Quick Cycle Technology for 27-Second Rise Time

Each lift features Quick Cycle technology with an upgraded pump (4cc vs the standard 2.5cc) that delivers a 27-second rise time and 17-second lowering time, over 40% faster than the standard 38-second configuration. The Quick Cycle system is engineered for high-volume service environments where minimizing vehicle transition time directly impacts daily throughput and revenue.

10,000 lb Capacity with 8.5" Chrome Pistons

Each unit provides 10,000 lb total lifting capacity with 2,500 lb per arm, handling passenger cars, crossovers, SUVs, and light trucks. The 8.5" diameter chrome pistons deliver greater stability under load than smaller-bore competitive designs, while the chrome non-breathing ram-style cylinder construction resists corrosion and extends service life.

Sealed Polymer Cassette Containment

Challenger EV Series inground lifts are fully contained in a sealed recycled polymer cassette tub that eliminates any risk of hydraulic fluid seeping into the surrounding soil or groundwater. This environmentally responsible design protects your facility from contamination liability while simplifying compliance with environmental regulations.

87" Drive-Thru Clearance

The 87" drive-thru clearance is among the widest in the inground lift category, accommodating full-size trucks, wide-bodied SUVs, and vehicles with extended mirrors or fender flares. The generous clearance minimizes tire pinching risk and provides confident drive-on access for a broad vehicle mix.

Over 50% More Bearing Contact Surface

Challenger EV Series lifts feature over 50% more bearing contact surface than competitive inground lifts, providing smoother operation and greater stability throughout the lift stroke. Enhanced raised wipers at both top and bottom of each bearing improve grease retention and minimize contaminant intrusion for reduced maintenance and longer component life.

• Multi-Bay Service Facilities: The set-of-2 configuration is designed for facilities installing or replacing multiple inground lift positions simultaneously, reducing procurement complexity and ensuring matched equipment across bays.
• Quick Lube and Express Service Centers: The 27-second Quick Cycle rise time accelerates vehicle transitions for express maintenance workflows including oil changes, inspections, tire rotations, and brake service where speed directly impacts daily revenue.
• Dealership Service Departments: ALI/ETL certified design meets professional standards and insurance requirements for warranty service. The flush-floor inground configuration provides a clean, modern service bay appearance.
• Fleet Maintenance Operations: The 10,000 lb capacity handles fleet service on passenger vehicles, vans, and light trucks. Quick Cycle speed supports high-volume scheduled maintenance programs with tight turnaround requirements.
• New Construction and Facility Expansion: The Less Superstructure (LS) configuration allows facilities to specify superstructure components separately, accommodating custom arm configurations or phased installation schedules.

Challenger EV1020LS-2-QC Installation Requirements

Electrical Requirements

Power: 208-230V, 60Hz, single phase per lift unit. Each EV1020-QC requires a dedicated 2HP motor circuit with 30A service. A licensed electrician must install and verify the electrical supply meets all local codes and manufacturer specifications.

Concrete Pit Construction

Foundation: Inground installation requires proper concrete pit construction per Challenger specifications. Concrete must meet minimum PSI requirements with proper reinforcement. The sealed polymer cassette tub is installed into the prepared pit before the completion kit and superstructure are assembled. Consult the installation manual for detailed pit dimensions and preparation requirements.

Pneumatic Requirements

Air Supply: 90-120 PSI compressed air required for lock release operation on each lift unit. Ensure your shop air system can maintain adequate pressure and volume for consistent operation across both lifts simultaneously.

Professional Installation Required

Professional installation by a qualified lift installer is required. Inground lift installation involves concrete work, electrical connections, and hydraulic system setup that must be performed correctly for safe operation and warranty coverage. Challenger can recommend certified installers in your area.

• Challenger EV1020-QC inground lift assembly with Quick Cycle pump upgrade
• Sealed polymer cassette tub
• 8.5" chrome pistons
• Chrome non-breathing ram-style cylinders
• Enhanced raised wipers (top and bottom)
• Mechanical safety locks (engaging every 3")
• Standard wall-mounted power controls
• Installation and operation manual

Challenger EV1020LS-2-QC Shipping and Delivery

Freight Shipping

Coverage: Free freight shipping to commercial addresses in the 48 contiguous United States. Lead Time: Contact sales for current lead times on set-of-2 orders. International: Contact sales for international shipping quotes and availability.

Delivery Requirements

Unloading: Forklift or loading dock required for unloading. Inground lift components ship on heavy pallets and require equipment capable of handling the shipping weight. Delivery Type: Curbside delivery to commercial addresses is standard. Inspection: Inspect all packages for damage before signing the bill of lading. Document and photograph any visible damage on the delivery receipt immediately.

Returns

Returns accepted within 30 days of delivery. Product must be unopened in original packaging with proof of purchase. A 20% restocking fee applies to all returns. Buyer is responsible for return freight costs.

• 5 Years: Structural components including cassette tub, plungers, and main frame assembly
• 2 Years: Functional parts including power units, cylinders, hoses, cables, and controls
• 1 Year: Electrical components and accessories

What does "Less Superstructure" (LS) mean?

Less Superstructure means this listing includes the complete inground lift units (cassette tub, pistons, power unit, controls, and safety locks) without the superstructure assembly. The EV1020SS superstructure kit, which includes 3-stage front and rear arms, double telescoping screw pads, extensions, and frame engaging adapters, must be purchased separately for each lift unit to achieve a fully operational lift system.

Why would I order the LS model instead of the complete lift?

The LS configuration is designed for facilities that are replacing lift mechanisms in existing pits where superstructure components are being retained, ordering superstructures separately to match specific service requirements, or phasing installation across multiple purchase orders. It allows flexible component sourcing while ensuring the core lift hardware is factory-matched.

How many lift units are included in this listing?

This listing includes 2 complete EV1020-QC inground lift units. Each unit is a self-contained inground lift with its own Quick Cycle power unit, 8.5" chrome pistons, sealed polymer cassette tub, mechanical safety locks, and wall-mounted controls. Both units ship together for coordinated multi-bay installation.

What is Quick Cycle and how fast is it?

Quick Cycle technology uses an upgraded pump (4cc vs the standard 2.5cc) to deliver a 27-second rise time and 17-second lowering time, compared to the standard EV1020's 38-second rise time. This represents over 40% faster operation, making Quick Cycle the preferred choice for high-volume service environments where faster lift transitions directly impact daily throughput.

What is the lifting capacity of each unit?

Each EV1020 lift unit has a total lifting capacity of 10,000 lb with 2,500 lb capacity per arm. This accommodates passenger cars, crossovers, SUVs, and light trucks. The 8.5" chrome pistons provide greater stability under load compared to smaller-bore competitive designs.

What is the difference between the EV1020 and EV1220?

The EV1020 has a 10,000 lb capacity with 2,500 lb per arm and a 97" overall width, while the EV1220 has a 12,000 lb capacity with 3,000 lb per arm and a 115" overall width. Both share the same 87" drive-thru clearance and 8.5" chrome pistons. The EV1020 offers a more compact footprint ideal for standard passenger vehicle service, while the EV1220 handles heavier commercial vehicles.

What electrical power does each lift require?

Each EV1020-QC lift unit requires 208-230V, 60Hz, single phase power with a dedicated 2HP motor circuit and 30A service. Since this is a set of 2 lifts, your facility will need 2 separate electrical circuits meeting these specifications. A licensed electrician must install and verify electrical supply for each unit.

What superstructure do I need to complete the lift?

Each lift unit requires one EV1020SS superstructure kit. The superstructure includes 3-stage front and rear arms with reach from 19.625" to 42.125", double telescoping screw pads adjustable from 3.875" to 6", standard and medium extensions, high extensions, and frame engaging truck adapters. Frame engaging adapters are required when lifting vehicles with frame construction.

Is compressed air required?

Yes, each lift unit requires compressed air at 90-120 PSI for the mechanical lock release mechanism. Ensure your shop air system can provide adequate pressure and volume for consistent operation across both lifts, especially during simultaneous use in adjacent bays.

Is this lift ALI/ETL certified?

Yes, the Challenger EV1020 carries both ALI (Automotive Lift Institute) and ETL certification, validating that the lift meets recognized safety and performance standards. This third-party certification provides documented compliance appropriate for professional service facilities and insurance requirements.

What warranty coverage is included?

Challenger provides a 5-year warranty on structural components, 2-year warranty on functional parts (power units, cylinders, hoses, controls), and 1-year warranty on electrical components. An optional extended warranty adding 3 years of functional parts coverage is available within 30 days of purchase. Warranty registration must be completed within 30 days of installation.

What maintenance does this lift require?

Challenger EV Series inground lifts require quarterly greasing of bearings, which is less frequent than competitive models that require monthly maintenance. Regular inspection of safety locks, hydraulic fluid levels, wipers, and piston condition should follow the maintenance schedule in the installation manual. The optional StayDry kit (SD100) automates condensate removal from the cassette tub.

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including styrene and vinyl chloride, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit www.p65warnings.ca.gov.
